Save 45%
E202/125
Key specifications
Rated current (Iu)Filter products by 125 A
Rated voltage (Ue)Filter products by 400 / 12 V
Number of polesFilter products by 2P
Max Break CapacityFilter products by 6 kA
Degree of protection (IP)Filter products by IP10
Product SeriesFilter products by E200

ABBModular Isolators Modular Contactors Modular ChangeoversPower Distribution & Protection

2CDE282001R0125 – E202/125 | ABB

Order code

List R959.04 Your price R527.47

Per unit · volume pricing available on request

excl. VAT R606.59 incl.

Listed in stock — availability is re-confirmed on every order

In stock — 1–2 working days if stocked locally, 3–5 working days if sourced

E202/125 — ABB order code 2CDE282001R0125. Rated current 125 A; 2P; breaking capacity 6 kA; rated voltage 400 / 12 V.

In stock — 1–2 working days if stocked locally, 3–5 working days if sourced

Download datasheet (opens in a new tab)Open 360° view (opens in a new tab)View on the ABB site (opens in a new tab)

Select a variant in this series

Rating125 A3 options
Poles2P4 options
Breaking capacity6 kA2 options
Rated voltage400 / 12 V2 options

Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.

Ordering & delivery
  • Contact us for bulk pricing, lead times and ordering codes.
  • Minimum order: 1 unit.
  • Manufacturer's standard warranty applies.
  • Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
  • Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
  • Authorised ABB distributor
  • Genuine product with manufacturer warranty
  • Formal quotations with written lead times
SKU: 2CDE282001R0125 Categories: , Tags: ,

Overview

2CDE282001R0125 — E202/125 from the ABB 2P 125A range. Listed under Modular Isolators Modular Contactors Modular Changeovers on the ABB catalogue at RMS-ABB.Africa.

About 2CDE282001R0125

These devices are suitable for commanding loads and they are realized according EN 60947-3 and EN 60669-1 respectively. Fast removal without dismantling of the busbar. Captive screws with recessed/slotted head. Pozidrive size 2. Add-on of up to 3 auxiliary contact S2C-H6R possible Integrated lay-on edge for labeling system ILS. Locking device as accessories for unauthorized ON/OFF. Approval: VDE, CCC, KEMA.

2CDE282001R0125 key specifications

Key specifications: rated current 125 A; 2P; breaking capacity 6 kA; rated voltage 400 / 12 V; rated operational voltage 230 / 400 V; 50 / 60 Hz; IP10; ambient −25 … +55 / −40 … +70 °C.

Ordering information for 2CDE282001R0125

2CDE282001R0125 — frequently asked questions

What is the rated current of 2CDE282001R0125?

2CDE282001R0125 is rated 125 A.

How many poles does 2CDE282001R0125 have?

2CDE282001R0125 is a 2P device.

What is the breaking capacity of 2CDE282001R0125?

The catalogue states 6 kA for 2CDE282001R0125. Check the datasheet for the value at your system voltage.

Where is the datasheet for 2CDE282001R0125?

The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where ABB publishes them.

Is 2CDE282001R0125 a genuine ABB product?

Yes. 2CDE282001R0125 is supplied through the manufacturer’s authorised channel with the standard ABB warranty, and every order is confirmed against stock before payment.

Documents

Published by the manufacturer for this part. Each one opens in a new tab.

Technical specifications

Data supplied by the manufacturer. Confirm against the official datasheet before ordering.

Identification & ordering

Order code2CDE282001R0125
Product NameFilter products by E202/125R
BrandFilter products by ABB, ABB Group, ABB Limited
Product SeriesFilter products by E200
GTIN / EAN4016779645966
RangeFilter products by 2P 125A

Electrical ratings

Number of polesFilter products by 2P
Rated current (Iu)Filter products by 125 A
Rated voltage (Ue)Filter products by 400 / 12 V
Rated operational voltageFilter products by 230 / 400 V
Operating VoltageFilter products by 230 / 400
Rated FrequencyFilter products by 50 / 60 Hz
Max Break CapacityFilter products by 6 kA
Pollution DegreeFilter products by 3

Power & coil

Power LossFilter products by 6.1 W

Environment & protection

Degree of protection (IP)Filter products by IP10
Ambient air temperatureFilter products by −25 … +55 / −40 … +70 °C

Standards & certification

Conformity to standardsFilter products by IEC/EN 60947-3

Documents

DatasheetDownload datasheet
RoHS declarationDownload RoHS declaration
Declaration of conformityDownload declaration of conformity
ABB product pageView on the ABB site
Deep LinkPrintable product summary
360° viewOpen 360° view
