Save 45% Genuine ABB
1SAM250000R1005 — 1SAM250000R1005 - MS116-1.0 ABB Motor Circuit Breakers

Key specifications

Rated current (Iu)
1 A
Rated voltage (Ue)
690 V
Number of poles
3P
Rated Frequency
50 Hz  ·  60 Hz
Degree of protection (IP)
IP20  ·  IP10
Product Series
MS116
ABB MS116 · Authorised distributor
Motor Circuit BreakersMotor Control and DrivesMotor Protection Circuit Breakers

1SAM250000R1005 – MS116-1.0 ABB Motor Circuit Breakers

Buy 1SAM250000R1005 – MS116-1.0 ABB Motor Circuit Breakers from ABB. Genuine ABB component for automation, motor control and electrical installations. MS116-1.0
Order code 1SAM250000R1005

Your price

Original price was: R837.78.Current price is: R460.78.
Save 45%

Excluding VAT · per unit · volume pricing available on request

Request a quote
Product datasheet View on ABB.com
Genuine ABB product — supplied through authorised channels.
Fast delivery across South Africa & Africa (lead time confirmed on order).
Off-site stock — availability is confirmed after quote request or order placement.

Overview

MS116-1.0 – 0.63-1.0 A, 50kA 400V The MS116-1.0 manual motor starter (also known as motor protection circuit breaker or manual motor protector) is a compact 45 mm width device with a rated operational current of Ie = 1.0 A. This device is used to manually switch on and off motors and to protect them reliably and without the need for a fuse from short-circuits, overload and phase failures. The manual motor starter offers a rated service short-circuit breaking capacity Ics = 50 kA at 400 VAC and trip class 10A. Further features are the build-in disconnect function, temperature compensation, trip-free mechanism and a rotary handle with a clear switch position indication. The manual motor starter is suitable for three- and single-phase applications. Auxiliary contacts, signaling contacts, undervoltage releases, shunt trips, 3-phase bus bars, power in-feed blocks and locking devices for protection against unauthorized changes are available as accessory.

1SAM250000R1005 – MS116-1.0 ABB Motor Circuit Breakers is a genuine ABB electrical component designed for industrial automation, motor control, and power distribution applications.

ABB products are widely used across commercial and industrial installations where reliability, safety, and long operational life are required.

Applications

  • Industrial automation
  • Motor control systems
  • Power distribution infrastructure
  • Commercial electrical installations

Browse Related Categories

Motor Circuit Breakers | Motor Control and Drives | Motor Protection Circuit Breakers

Technical specifications

Data supplied by ABB. Please confirm against the official datasheet before ordering.

Ordering & identification

Order code
1SAM250000R1005
Product Name
MS116-1.0
Product Series
MS116
Brand
ABB  ·  ABB Group  ·  ABB Limited
International GTIN
4013614320286.0

Electrical ratings & operation

Rated current (Iu)
1 A
Rated voltage (Ue)
690 V
Rated Frequency
50 Hz  ·  60 Hz
Rated operational voltage
690 V
Operating Voltage
690 V
Operating Current AC
1 A
General Use Rating UlC
1.0
Number of poles
3P
Degree of protection (IP)
IP20  ·  IP10
Pollution Degree
3.0

Power & coil characteristics

Power Loss
0.6 … 1.6
Con Fre Air The Cur
1 A

Environment

Ambient air temperature
-25 … +70  ·  -50 … +80  ·  '-25 … 55  ·  0 … +40

Documents & media

Datasheet
Download datasheet
RoHS declaration
Download RoHS declaration
Declaration of conformity
Download declaration of conformity
Dimensions Drawings
Download dimension drawings
ABB product page
View on ABB.com
Deep Link
Open deep link
360° view
Open 360° view

Documents & downloads

Official ABB documentation for this order code.

Technical datasheetPDF · ABB Library RoHS declarationPDF · Compliance Declaration of conformityPDF · Compliance Dimension drawingsPDF · Engineering View on ABB.comManufacturer page 360° product viewInteractive
