About 1SVR740180R3300

The CT-APS.22P is a single-function electronic time relay from the CT-S timer range. It provides an OFF-delay (delay on break) function with 10 time ranges from 0.05 s to 300 h.This time relay operates with a rated control supply voltage of 24 – 48 V DC / 24 – 240 V AC and has a 2 c/o (SPDT) output with contacts rated at 250 V / 4 A. A control input works with voltage-related (non-floating) triggering. A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers maintenance free Easy Connect Technology with push-in terminals.

1SVR740180R3300 key specifications

Key specifications: rated current 4 A; rated voltage 48 V; measuring range 24-48V.

Ordering information for 1SVR740180R3300

• Order code: 1SVR740180R3300
• Manufacturer: ABB
• Range: CT-APS.22P – OFF-delay, 24-48V DC/24-240V AC, 10 (0.05 s – 300 h), 2 c/o
• Supplied: each
• Datasheet: manufacturer datasheet for 1SVR740180R3300

1SVR740180R3300 — frequently asked questions

What is the rated current of 1SVR740180R3300?

1SVR740180R3300 is rated 4 A.

Where is the datasheet for 1SVR740180R3300?

The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where ABB publishes them.

Is 1SVR740180R3300 a genuine ABB product?

Yes. 1SVR740180R3300 is supplied through the manufacturer’s authorised channel with the standard ABB warranty, and every order is confirmed against stock before payment.
