1SVR730700R2200 – CM-MSS.23S Therm. motor protec. relay | ABB

1SVR730700R2200 — CM-MSS.23S Therm. motor protec. relay from the ABB CM-MSS.23S – 110-130V AC/220-240V AC, sensor PTC type A range. Listed under Thermistor Motor Protection Relays on the ABB catalogue at RMS-ABB.Africa.

About 1SVR730700R2200

The CM-MSS.23S belongs to the CM-MSS thermistor motor protection relay range. It operates with a rated control supply voltage of 110-130 V AC and 220-240 V AC and has a 2 c/o (SPDT) output with contacts rated at 250 V / 4 A. It features one sensor circuit to monitor PTC temperature sensors and works according to the closed-circuit principle. The relay can be reset automatically, manually or remotely after the failure has been removed. A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers screw connection technology with double-chamber cage connection terminals.

1SVR730700R2200 key specifications

Key specifications: rated voltage 250 V; 110 … 130 / 220 … 240 V coil; 50 / 60 Hz; IP50 / IP20; ambient −25 … +60 / −40 … +85 °C; to CAN/CSA C22.2 No.14|IEC/EN 63000|IEC/EN 60947-5-1|IEC/EN 60947-8|UL 508.

Ordering information for 1SVR730700R2200

• Order code: 1SVR730700R2200
• Manufacturer: ABB
• Range: CM-MSS.23S – 110-130V AC/220-240V AC, sensor PTC type A
• GTIN / EAN: 4013614496691
• Supplied: each
• Datasheet: manufacturer datasheet for 1SVR730700R2200

1SVR730700R2200 — frequently asked questions

What coil or control voltage does 1SVR730700R2200 use?

1SVR730700R2200 is supplied with a 110 … 130 / 220 … 240 V coil. Other coil voltages in the range appear under “Ordering options” above where the catalogue lists them.

Where is the datasheet for 1SVR730700R2200?

The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where ABB publishes them.

Is 1SVR730700R2200 a genuine ABB product?

Yes. 1SVR730700R2200 is supplied through the manufacturer’s authorised channel with the standard ABB warranty, and every order is confirmed against stock before payment.
