Save 45%
CM-IWS.2S Insulation monitoring relay
Key specifications
Rated voltage (Ue)Filter products by 0 … 400
Coil voltage (Uc)Filter products by 24 … 240 V
Degree of protection (IP)Filter products by IP50 / IP20
Product SeriesFilter products by CM-IWS

ABBInsulation Monitoring RelaysModular Protection RelaysTimers and Control Relays

1SVR730670R0200 – CM-IWS.2S Insulation monitoring relay | ABB

Order code

Select a variant in this series

Poles

Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.

List R4 410.77 Your price R2 425.92

Excluding VAT · per unit · volume pricing available on request

Listed in stock — availability is re-confirmed on every order

CM-IWS.2S Insulation monitoring relay — ABB order code 1SVR730670R0200. 24 … 240 V coil; IP50 / IP20; ambient −25 … +60 / −40 … +85 °C; measuring range 1 … 100.

Download datasheet (opens in a new tab)Open 360° view (opens in a new tab)View on the ABB site (opens in a new tab)

Accessories & add-ons 8
Ordering & delivery
  • Contact us for bulk pricing, lead times and ordering codes.
  • Minimum order: 1 unit.
  • Manufacturer's standard warranty applies.
  • Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
  • Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
  • Authorised ABB distributor
  • Genuine product with manufacturer warranty
  • Formal quotations with written lead times
SKU: 1SVR730670R0200 Categories: , , Tags: , ,

Overview

1SVR730670R0200 — CM-IWS.2S Insulation monitoring relay, an insulation fault monitoring relay, insulation relay, insulation monitoring, insulation faults from the ABB CM-IWS.2S – 24-240V AC/DC, measuring 1…100 kΩ range. Listed under Insulation Monitoring Relays on the ABB catalogue at RMS-ABB.Africa.

About 1SVR730670R0200

The CM-IWS.2S serves to monitor insulation resistance in accordance with IEC 61557-8 in unearthed.

1SVR730670R0200 key specifications

Key specifications: 24 … 240 V coil; IP50 / IP20; ambient −25 … +60 / −40 … +85 °C; measuring range 1 … 100; to CAN/CSA C22.2 No.14|IEC/EN 63000|IEC/EN 61326-2-4|IEC/EN 61557-1|IEC/EN 61557-8|UL 508.

Ordering information for 1SVR730670R0200

1SVR730670R0200 — frequently asked questions

What coil or control voltage does 1SVR730670R0200 use?

1SVR730670R0200 is supplied with a 24 … 240 V coil. Other coil voltages in the range appear under “Ordering options” above where the catalogue lists them.

Where is the datasheet for 1SVR730670R0200?

The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where ABB publishes them.

Is 1SVR730670R0200 a genuine ABB product?

Yes. 1SVR730670R0200 is supplied through the manufacturer’s authorised channel with the standard ABB warranty, and every order is confirmed against stock before payment.

Technical specifications

Data supplied by the manufacturer. Confirm against the official datasheet before ordering.

Identification & ordering

Order codeFilter products by 1SVR730670R0200
Product NameFilter products by CM-IWS.2S
BrandFilter products by ABB, ABB Group, ABB Limited
Product typeFilter products by Insulation fault monitoring relay, insulation relay, insulation monitoring, insulation faults
Product SeriesFilter products by CM-IWS
GTIN / EANFilter products by 4016779852616
RangeFilter products by CM-IWS.2S – 24-240V AC/DC, measuring 1…100 kΩ

Electrical ratings

Rated voltage (Ue)Filter products by 0 … 400
Rated Control Supply VoltageFilter products by 24 … 240
Rated FrequencyFilter products by 50 / 60, Filter products by 15 … 400, Filter products by DC
Pollution DegreeFilter products by 3

Power & coil

Coil voltage (Uc)Filter products by 24 … 240 V
Power LossFilter products by 2 W

Sensing & measurement

Measuring RangeFilter products by 1 … 100

Environment & protection

Degree of protection (IP)Filter products by IP50 / IP20
Ambient air temperatureFilter products by −25 … +60 / −40 … +85 °C

Standards & certification

Conformity to standardsFilter products by CAN/CSA C22.2 No.14, Filter products by IEC/EN 61326-2-4, Filter products by IEC/EN 61557-1, Filter products by IEC/EN 61557-8, Filter products by IEC/EN 63000, Filter products by UL 508

Documents

DatasheetDownload datasheet
RoHS declarationDownload RoHS declaration
Declaration of conformityDownload declaration of conformity
Dimension drawingsDownload dimension drawings
ABB product pageView on the ABB site
Deep LinkPrintable product summary
360° viewOpen 360° view

Documents

Published by the manufacturer for this part. Each one opens in a new tab.

Accessories & add-ons

8 items

More in the CM-IWS range

3 items

Same series, same mounting and the same documentation set.

Similar items

2 items

Alternatives on our other RMS storefronts

RMS supplies each manufacturer range from its own storefront. These links open a different RMS site in a new tab.

Quick answers

What is 1SVR730670R0200?

1SVR730670R0200 is the order code for CM-IWS.2S Insulation monitoring relay. It belongs to our Insulation Monitoring Relays range. RMS-ABB.Africa supplies it as genuine ABB product, sourced through the manufacturer's distribution channel.

Is it available?

It is listed as in stock. Availability is re-confirmed on every order before any payment is taken, so what you order is what actually ships.

How do I get a formal quotation?

Use "Add to quote" and submit the quote basket. The RMS team prices every line, confirms stock, and emails you a formal quotation with written lead times — and you can accept it online to turn it into an order.

Do I pay when I order?

No. Checkout submits the order without payment; we confirm stock for every line first, then email you a secure payment link for the order.
