ABBAF 4-Pole ContactorsContactorsMotor Control and Drives
1SFL607102R1200 – AF370-40-00-12
Order code
- 370 A
- 370 A
Original price was: R33 457.81.R18 401.79Current price is: R18 401.79.
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
Buy 1SFL607102R1200 – AF370-40-00-12 ABB AF 4-Pole Contactors from ABB. Genuine ABB component for automation, motor control and electrical installations. AF370-40-00-12
Download datasheet (opens in a new tab)View on the ABB site (opens in a new tab)Open deep link (opens in a new tab)
Accessories & add-ons 8
- BER16-4KF, Connection sets1SBN081322R1000 Original price was: R403.50.R221.92Current price is: R221.92.Add
- AF750-30-11, 48-130V AC/DC coil1SFL637001R6911 Original price was: R56 669.42.R31 168.18Current price is: R31 168.18.Add
- AF750-30-11, 100-250V AC/DC coil1SFL637001R7011 Original price was: R56 669.42.R31 168.18Current price is: R31 168.18.Add
- AF750-30-11, 250-500V AC/DC coil1SFL637001R7111 Original price was: R56 669.42.R31 168.18Current price is: R31 168.18.Add
- BER16C-3 Connection sets1SBN081012R1000 Original price was: R253.37.R139.36Current price is: R139.36.Add
- BEY16C-3 Connection sets1SBN081018R2000 Original price was: R331.50.R182.33Current price is: R182.33.Add
- AF750-30-11, 24-60V DC coil1SFL637001R6811 Original price was: R56 669.42.R31 168.18Current price is: R31 168.18.Add
- VM3 mechanical interlock1SBN031005T1000 Original price was: R138.28.R76.05Current price is: R76.05.Add
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery nationwide, and export across Africa.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised ABB distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
AF190…AF370 range – AC-1 525A, 4NO, 48-130V AC/DC coil The AF370-40-00-12 is a 4 pole – 1000 V IEC or 600 V UL contactor with Main Circuit Bars, controlling motors up to 200 kW / 400 V AC (AC-3) / and switching power circuits up to 525 A (AC-1) or 420 A UL general use. Thanks to the AF technology, the contactor has a wide control voltage range (48-130 V 50/60 Hz and DC), managing large control voltage variations, reducing panel energy consumptions and ensuring distinct operations in unstable networks. Furthermore, surge protection is built-in, offering a compact solution. AF contactors have a block type design, can be easily extended with add-on auxiliary contact blocks and an additional wide range of accessories.
1SFL607102R1200 – AF370-40-00-12 ABB AF 4-Pole Contactors is a genuine ABB electrical component designed for industrial automation, motor control, and power distribution applications.
ABB products are widely used across commercial and industrial installations where reliability, safety, and long operational life are required.
Applications
- Industrial automation
- Motor control systems
- Power distribution infrastructure
- Commercial electrical installations
Browse Related Categories
AF 4-Pole Contactors | Motor Control and Drives | Contactors
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Order code | Filter products by 1SFL607102R1200 |
|---|---|
| Product Name | Filter products by AF370-40-00-12 |
| Brand | Filter products by ABB, ABB Group, ABB Limited |
| Product Series | Filter products by AF370 |
| International GTIN | Filter products by 7320500504352 |
Electrical ratings
| Number of poles | Filter products by 4P |
|---|---|
| Rated current (Iu) | Filter products by 370 A |
| Rated voltage (Ue) | Filter products by 1000 V |
| Rated operational voltage | Filter products by 1000 V |
| Operating Voltage | Filter products by 1000 V |
| Rated Control Circuit Voltage | Filter products by 48 … 130 |
| Operating Current AC | Filter products by 370 A |
| General Use Rating UlC | Filter products by 520.0 |
| Rated Frequency | Filter products by 50 / 60, Filter products by 60 Hz |
| Max Break Capacity | Filter products by 5000 kA |
Power & coil
| Coil Consumption | Filter products by 1225.0 VA, Filter products by 2.0 VA, Filter products by 23.2 VA, Filter products by 975.0 VA |
|---|---|
| Coil Operating limits | Filter products by 0.85 x Uc Min. … 1.1 x Uc Max. (at θ ≤ 70 °C) |
| Con Fre Air The Cur | Filter products by 525 A |
| Power Loss | Filter products by 72 W |
Environment & protection
| Degree of protection (IP) | Filter products by IP20, Filter products by IP00, Filter products by IP40 |
|---|---|
| Ambient air temperature | Filter products by -25 … +50, Filter products by '-40 … 70 |
Documents
| Datasheet | Download datasheet |
|---|---|
| RoHS declaration | Download RoHS declaration |
| Declaration of conformity | Download declaration of conformity |
| Dimension drawings | Download dimension drawings |
| ABB product page | View on the ABB site |
| Deep Link | Open deep link |
