Save 45% Genuine ABB
1SBL113001R8101 — 1SBL113001R8101 - ASL12-30-01-81 ABB AS 3-Pole Contactors

Key specifications

Rated current (Iu)
11.0 A  ·  12.0 A  ·  7.0 A
Rated voltage (Ue)
690 V
Max Break Capacity
155.0 kA  ·  90.0 kA
Rated Frequency
50 / 60
Degree of protection (IP)
IP20
Product Series
ASL12
ABB ASL12 · Authorised distributor
AS 3-Pole ContactorsContactorsMotor Control and Drives

1SBL113001R8101 – ASL12-30-01-81 ABB AS 3-Pole Contactors

Buy 1SBL113001R8101 – ASL12-30-01-81 ABB AS 3-Pole Contactors from ABB. Genuine ABB component for automation, motor control and electrical installations. ASL12-30-01-81
Order code 1SBL113001R8101

Your price

Original price was: R716.90.Current price is: R394.30.
Save 45%

Excluding VAT · per unit · volume pricing available on request

Request a quote
Product datasheet View on ABB.com
Genuine ABB product — supplied through authorised channels.
Fast delivery across South Africa & Africa (lead time confirmed on order).
Off-site stock — availability is confirmed after quote request or order placement.

Overview

AS12 range – AC-3 12A, AC-1 24A, 1NC aux, 24V DC coil ASL12 contactors are mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC or 220 V DC. They are mainly used for controlling 3-phase motors, non-inductive or slightly inductive loads. The ASL… series 1-stack 3-pole contactors are of the block type design. – Main poles and auxiliary contact blocks: 3 main poles, 1 built-in auxiliary contact, front-mounted add-on auxiliary contact blocks (mechanically-linked auxiliary contacts compliant with Annex L of IEC 60947-5-1. N.C. mirror contacts compliant with Annex F of IEC 60947-4-1) – Control circuit: DC operated with solid core magnet circuit. The polarity on the coil terminals (A1+ and A2-) must be respected – Accessories: a wide range of accessories is available. ASL… contactors are fitted with low consumption DC coils and are suitable for a direct control by PLC outputs.

1SBL113001R8101 – ASL12-30-01-81 ABB AS 3-Pole Contactors is a genuine ABB electrical component designed for industrial automation, motor control, and power distribution applications.

ABB products are widely used across commercial and industrial installations where reliability, safety, and long operational life are required.

Applications

  • Industrial automation
  • Motor control systems
  • Power distribution infrastructure
  • Commercial electrical installations

Browse Related Categories

AS 3-Pole Contactors | Motor Control and Drives | Contactors

Technical specifications

Data supplied by ABB. Please confirm against the official datasheet before ordering.

Ordering & identification

Order code
1SBL113001R8101
Product Name
ASL12-30-01-81
Product Series
ASL12
Brand
ABB  ·  ABB Group  ·  ABB Limited
International GTIN
3471523059511.0

Electrical ratings & operation

Rated current (Iu)
11.0 A  ·  12.0 A  ·  7.0 A
Rated voltage (Ue)
690 V
Rated Frequency
50 / 60
Rated operational voltage
690 V
Operating Voltage
690 V
Operating Current AC
11.0 A  ·  12.0 A  ·  7.0 A
Rated Control Circuit Voltage
24 V
General Use Rating UlC
20.0
Max Break Capacity
155.0 kA  ·  90.0 kA
Degree of protection (IP)
IP20

Power & coil characteristics

Power Loss
0.3 W  ·  1.2 W
Low Coil Consumption
Yes
Con Fre Air The Cur
10.0 A  ·  25.0 A

Environment

Ambient air temperature
-25 … +60  ·  -60 … +80  ·  '-40 … 70

Documents & media

Datasheet
Download datasheet
RoHS declaration
Download RoHS declaration
Declaration of conformity
Download declaration of conformity
Instructions for Use
Download instructions
Dimensions Drawings
Download dimension drawings
ABB product page
View on ABB.com
Deep Link
Open deep link

Documents & downloads

Official ABB documentation for this order code.

Technical datasheetPDF · ABB Library RoHS declarationPDF · Compliance Declaration of conformityPDF · Compliance Dimension drawingsPDF · Engineering Instructions for usePDF · Manual View on ABB.comManufacturer page

Ordering & delivery

How to order

Contact us for bulk pricing, lead times and ordering codes. Add the item to your cart to order online, or request a quotation if you need a formal quote document, project pricing or a written lead time.

Stock & lead time

Some items are held off-site rather than in our Johannesburg warehouse. Where that is the case, availability is confirmed once a quote is requested or an order is placed, and the lead time is confirmed in writing on your quotation.

Delivery

Nationwide delivery across South Africa, export delivery to the rest of Africa on request, and collection available from our Johannesburg branch.
